Hydraulic Overbed Table

Technical Specifications

• Stretcher frame fitted with metal patient support in 2 sections
• Basic foldable wheelchair for adult.
• Heavy carriage mounted on 4 anti-static ball-bearing wheels.
• Front wheels free rolling, 360 degrees swivel.
• Both rear wheels with brake.
• Foot lever, integrated in frame, facilitates tilting the wheelchair.
• Two handles at the rear fit with plastic rims.
• Swing-away foot and arm supports for easy stepping on/off.
• Armrests seat and back are upholstered.

Materials

• High resistance to corrosion (tropical environment).
• Frame: epoxy coated tubular steel.
• Upholstery: plastic, flexible highly tear resistant, anti-static, flame retardant, disinfectant- and liquid proof, washable.
• Tires: heavy duty solid rubber.

Dimensions

• Overall: approx. 450 x 500 x 850 mm (d x w x h).
• Back support: approx. 500 x 400 mm (w x h).
• Frame, diameter: approx. 25 mm.
• Wheels, diameter: front approx. 200 mm, rear approx. 600 mm.
• Carrying capacity: approx. ≥ 150 kg.

Quality Standards & Safety

• US-FDA/CE approved
• Brand and Model engraved/embossed/printed
• Country of manufacturer and country of shipment same Bangladesh

Warranty, Spare Parts Availability & After Sale Service

• • Comprehensive 1 (one) year warranty with all spare parts and accessories (without consumables) after the date of installation & commissioning (functioning).
• Availability of spares parts must be for 3 years after the date of installation & commissioning (functioning).

• Minimum 4 (Four) motor system
• Electrical adjustments of backrest, footrest, height, Trendelenburg and Reverse Trendelenburg
•  Various positions Fowler, Vascular and Cardiac
• Auto contour for optimum positioning to evenly distribute and to help prevent patient from sliding towards fool end of the bed
• Hand control unit
•  Auto-CPR button and Manual CPR for backrest.
•  CPR switch, in the event of the bed occupant suddenly requiring cardiopulmonary resuscitation the bed can be flattened within few seconds without sudden fall of the backrest (Automatic and Manually).
• The spring / Hydraulic system, which ever you are giving, should be easily cleanable corrosion resistant and decontaminated desire life span of ICU Bed recommended by manufacturer.
• Auto-regression system,
• Waterproof Nurse Control panel with backlight system.
•  Single button option for Trendelenburg, Cardiac, Examination, Vascular and Patient Evacuation.
•  Flashlight / LED light feature integrated on nurse control panel,
•  Detachable stainless (Medical Grade-ASI-316) & HIPL structure, ABS /Polyethylene resin/ Polypropylene head and foot boards with push handles & angle indicator
• Easily cleanable, lockable and fold-down ABS / Polypropylene/Powder coated steel/Polyethylene resin & should have non-slip grip & lockable when pressure applied over side rail by the patient or anybody.
•  4 section, detachable easy cleanable HPL mattress platform
• Lwering the height till 45-75 cm or more with nurse control to ensure safety and easy use
•  Sub frame constructed with stainless non-magnetic steel (Medical Grade-ASI-316)/Epoxy Powder coated steel
•  Gradually adjustable footrest
•  Drainage bag hooks at both sides
•  IV pole sockets located at four corners
•  Height adjustable non-magnetic stainless steel (Medical Grade-ASI-316) IV pole and IV pole max height 1.5m +10% approx. of same brand.
• The bed mounted on two or more telescopic columns or robust scissor mechanism.
•  Have protective Corner roller bumpers at four corner.
• 360 degree swivel and central lockable castors & can be fixed unidirectional during bed movement
• X-ray cassette holder at backrest
•  Liquid ingress protection
• Built in Battery backup function minimum 30 minutes after main power failure.

• Bed Dimensions: 103 x 228 cm + 10%
• Height Adjustment (without mattress): min. 45-75 cm or wider range (approx.) (adjustable with bed dimensions)
• Mattress Platform: min. (88 x 200)cm + 5%
• Backrest angle: 0° – 64°  or more
• Footrest angle: 0° -21° or wider
• Trendelenburg angle: 0° -12° or more
• Reverse Trendelenburg angle: 0° -13° or more
• Castor diameter: min. 125 mm.
• Under bed clearance: min, 8cm at height of 34 cm
• Safe Working Load: 220 kg or more.
• Power input: 220 + 10% VAC, 50Hz

• Foam Mattress consists of foam with a density of 38 kg/m3 foam and cuttings over the full width of the mattress.
• CNC cutting reducing contact points so distribute and reduce pressure on human body.
• Air passages, provide air circulation and prevent heat accumulation.
• Air passages reduce perspiration.
• Provides with anti-bacterial, waterproof, and breathable cover.
• Optimal thickness is 15 cm
• Size: adjustable with mattress platform according to manufacturer’s standard.
• Density: 38±2kg/m3
• Cleaning: Autoclavable at 80 deg
• Cover should be Flame resistant, Durable, Urine and blood resistance, Scratch-proof, Dirt resistant, Antibacterial & Antifungal, Water vapor permeable, Resistant to conventional disinfectants.

• ABS /Polypropylene/ Polyethylene resin Platform
• Epoxy painted metallic construction.
• Diagonal lockable castors.
• External Dimensions: min. (45 x 45 x 78 cm. (± 5%).

• Oxygen bottle Holder-01 nos.
• File Holder-01 nos.
• Lifting pole-01 nos.
• IV pole-01 nos.
• Mattress-01 nos.
• Bedside Locker-01 nos.
• Adjustable food tray with four lockable castor- 1 nos.

• US-FDA/CE approved
• Brand and Model engraved/embossed/printed
• Country of manufacturer and country of shipment same Bangladesh

• • Comprehensive 1 (one) year warranty with all spare parts and accessories (without consumables) after the date of installation & commissioning (functioning).
• Availability of spares parts must be for 3 years after the date of installation & commissioning (functioning).
